MAGEWELL
Director Plus
Part Number: 55290
A portable, all-in-one 4K live production and presentation system
- Flexible connectivity for AV sources, IP streams, media files and the third-party app
- Enhanced networking with 5G, Wi-Fi 6E, and 2.5GbE
- End-to-end 4K production from source ingest to streaming and recording
- Intuitive control for seamless workflow integration
Warranty Term: 2 Years Device / 1 Year Screen
PRODUCT DETAILS
Inputs
- 6 wired AV signals from HDMI and USB ports
- 10 simultaneous live IP sources (SRT, RTMP, RTSP, NDI® High Bandwidth, NDI HX2, NDI HX3)
- Media files (video, image, music, etc.)
- Webpage Inputs
- Up to 3 third-party apps from a whitelist
Streaming
- Natively supports streaming to YouTube, Twitch and Facebook Live
- Stream via SRT, RTMP, RTMPS, RTSP and NDI HX3
- Supports customizing encoding parameters and selecting the encoding source for ISO streaming
- Supports streaming to four destinations simultaneously
Features
- Shows can be created in landscape (16:9) or portrait (9:16) mode
- Supports free composition and switch while also providing layout templates for easy creation
- Powerful production tools including chroma keying, graphics, telestration and more
- Display multiple GFXs, including titles, lower thirds, a scoreboard, timer, stopwatch, etc.
- Supports autoplay and VFA (Video-follow-audio) auto switch
Recording
- Supports saving recording files to local storage, SD card, or USB SSD
- Supports splitting recording files by time or size
- Supports ISO recording, to record four of different sources simultaneously, or record multi-channel images with different quality for one source
Outputs
- HDMI OUT: Program, Preview, Multi-View, Duplicate Screen, HDMI 1/2/3/4, Webcam 1/2, Stream, App
- USB-C OUT: Program, Preview, Multi-View, Duplicate Screen, HDMI 1/2/3/4, Webcam 1/2, Stream, App
